Heavy Duty 26 Amp Air Compressor Pressure Switch Control Valve 95-125 PSI 4 Port
Heavy Duty 26 Amp Air Compressor Pressure Switch Control Valve 95-125 PSI 4 Port Heavy Duty 26 Amp Air Compressor Pressure Switch Control Valve 95-125 PSI 4 Port Heavy Duty 26 Amp Air Compressor Pressure Switch Control Valve 95-125 PSI 4 Port Heavy Duty 26 Amp Air Compressor Pressure Switch Control Valve 95-125 PSI 4 Port Heavy Duty 26 Amp Air Compressor Pressure Switch Control Valve 95-125 PSI 4 Port

Heavy Duty 26 Amp Air Compressor Pressure Switch Control Valve 95-125 PSI 4 Port

$15.88 USD

HEAVY DUTY 26 AMP PRESSURE SWITCH

Brand new Air Compressor Control Valve (95-125 PSI Pressure Switch). It is comparable to a Furnas, Square D, and many more. The product has an On/Off switch and a unloader. It will be working on both 2 stage and single stage compressors. If your compressor does not need the unloader, you do not have to hook it up.

  • PRESET 95-125 PSI
  • ¼" COMPRESSION UNLOADER VALVE
  • ¼" FEMALE NPT TANK CONNECTION WITH 3 EXTRA 1/4" PORTS.
  • MAX AMPS, 26 AMPS AT 120VOLT / 12 AMP AT 240 VOLT , AND 9.6 AMP AT 3PH 240 VOLT



BURST PRESSURE (PSI)

500

NUMBER OF PORTS

4

PORT TYPE

4-Port 1/4" NPT (Female)

UNLOADER

1/4" Compression

ACTUATION TYPE

Diaphragm

MANUAL SWITCH ACTION

Auto/ Off

PHASE

Single

CONTACT TYPE

DPST

AMPS

26

HP @ 1 PHASE - 120V

2

HP @ 1 PHASE - 230V

3

ENCLOSURE

NEMA 1

TEMP. RANGE (F)

-22 to 257

STANDARDS

UL/CSA

SERIES

LF10

WEIGHT

0.850000
